Thales Simplicity II


Reference-Tonearm

The Thales Simplicity II sets the benchmark for what is possible in tonearm-design today. The tracking geometry is based on a unique tetragon solution that reduces the tracking-error to 0,006°. Our new TTF-bearing-technology makes sure the performance achieves a level never reached before, as the micro-ball-bearings are arranged in a tension-free setup. The intrinsic frequencies of the two tonearm tubes are carefully tuned to improve on the damping properties of any single arm tube design.

The Thales Simplicity II comes with a special tool to make sure the installation is as precise as the manufacturing. The headshell can be removed very easily for exact alignment of the cartridge. Three different counterweights, each with a different mass are supplied to enable a wide range of cartridges to be used (7 to 23 grams).

The tonearm is available in bronze, grey or black anodized finish and is featured with Thales’s own internal wiring. This wiring is very flexible and made of purest copper. Options for the outlet are either an integrated 5-pin-DIN-connector or direct wiring to the amplifier.
Effective mass
18g
Cartridge weight
7…23g
Mounting distance
230mm
Offset angle
variable
Max. tracking error
0,006°
VTA adjustment
Thread
Azimuth adjustment
Thread, spring loaded
Coating
Chrome, anodized
Signal output (standard)
5-Pin DIN outlet
Signal output (option)
Direct wiring
Datasheet
Manual
